Knuckle Boom Marine Crane
description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

Knuckle Boom Marine Crane with enough strong structure can be operated in the most severe weather conditions. With the special knuckle boom structure, the marine crane leaves so much free space on the deck.


Knuckle Boom Marine Cranes are designed to lift high loads with extended jib and provide the operator with great flexibility during lifting operations.

Details

Parameters

Model

Outreach
(M)

Lifting Capacity
(T)

Lifting Moment
(KNM)

Total Moment
 (KNm)

Pedestal Diameter
(Mm)

Dead Weight
(Kg)

F-KB650

5.54-19.84

11.5-2.05

406.7-619.2

650

1560

7500-9500

F-KB800

5.54-19.84

14.2-2.8

555.5-774

800

1560

8100-10250

F-KB1000

5.54-19.84

17.8-3.5

694.4-967.5

1000

1560

8700-10850

F-KB1300

6.72-20.6

18.0-4.2

865.2-1165.0

1300

1850

9600-15500

F-KB1500

6.72-20.6

20.8-4.7

968.2-1323.4

1500

1850

12000-16500

F-KB1800

6.72-20.6

24.5-5.8

1194.8-1584.4

1800

2060

16200-19400

F-KB2300

6.92-21.8

30.0-6.8

1482.4-1992.6

2300

2060

25800-30000

F-KB2800

6.92-21.8

39.0-9.0

1962-2575.8

2800

2250

19200-23000

F-KB 3400

6.92-21.8

45.0-10.5

2354.4-2916

3400

2250

2830



Note:  We can design and manufacture according to customers’ requirements.
