Four Ropes Orange Peel Grab

Home  >  Products  >  Grab Bucket  >  Four Ropes Orange Peel Grab

Four Ropes Orange Peel Grab

sales@finergrab.com

Tel: 008618917581957

Whatsapp: 8618917581957

Four Ropes Orange Peel Grab
description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

The four-rope orange peel grab has two support ropes and two opening and closing ropes, which are wound around the drum of the crane support mechanism and the opening and closing mechanism. The four-rope grab is reliable, easy to operate and has high productivity. Because of the use of double support rope and double opening and closing rope, the four-rope grab has a greater total weight, and is widely used in the loading and unloading of coal, ore, grain, fertilizer, wood, wood chips, bread iron and other materials as well as port dredging operations.


Details

Parameters

Model

SWL
(t)

 Volume
(m³)

Dead Weight
(t)

Dia.of Pulley
(mm)

Dia.of Rope
(mm)

Pulley Multiplier
(m)

FRO 5[2.5]3

5

2.5

3

315

Φ16

3

FRO 10[3~5]5

10

3~5

5

450

Φ22

3~5

FRO 16[3~8]7.5

16

3~8

7.5

500

Φ26

3~5

FRO 20[5~10]9

20

5~10

9

560

Φ28

3~5

FRO 25[6~12]11

25

6~12

11

630

Φ32

3~5

FRO 32[8~15]14

32

8~15

14

710

Φ36

3~5

FRO 40[9~16]17

40

9~16

17

800

Φ40

3~5

FRO 45[10~20]18.5

45

10~20

18.5

900

Φ44

3~5
